(This is more of a potential improvement than a bug – I'm not really sure if this is the appropriate place for it).
I was profiling a mod I was working on, and found that I was getting a lot of branch mispredicts in Minecraft's perlin noise generator, in particular the gradient function. I was able to eliminate some of the branches, to get a 2.5% time reduction in world gen. (Obviously I'm working with decompiled code – hopefully in this case it is similar enough to your code that you can tell what I'm talking about).In the gradient function, the return statement is something like this:
return ((perm & 1) == 0 ? x : -x) + ((perm & 2) == 0 ? y : -y);
which costs you one branch mispredict per function call on average (since perm is random). It can be replaced with this:
int flip1 = -((
var8& 1) << 1) + 1;
int flip2 = -(var8& 2) + 1;
return flip1*var9+ flip2*var11;which gets most of the speed increase I mentioned. Earlier in the function you branch on the condition:
perm != 12 && perm != 14
which can be slightly improved to:
(perm | 0x2) != 14
In theory the compiler could then compile the remaining branches down into conditional moves, thus eliminating branch mispredict costs altogether, however it doesn't seem to be able to generate floating-point conditional move instructions at the moment (integer conditional move works fine).
(This is more of a potential improvement than a bug – I'm not really sure if this is the appropriate place for it).
I was profiling a mod I was working on, and found that I was getting a lot of branch mispredicts in Minecraft's perlin noise generator, in particular the gradient function. I was able to eliminate some of the branches, to get a 2.5% time reduction in world gen. (Obviously I'm working with decompiled code – hopefully in this case it is similar enough to your code that you can tell what I'm talking about).In the gradient function, the return statement is something like this:
return ((perm & 1) == 0 ? x : -x) + ((perm & 2) == 0 ? y : -y);
which costs you one branch mispredict per function call on average (since perm is random). It can be replaced with this:
int flip1 = -((perm & 1) << 1) + 1;
int flip2 = -(perm & 2) + 1;
return flip1*x + flip2*y;which gets most of the speed increase I mentioned. Earlier in the function you branch on the condition:
perm != 12 && perm != 14
which can be slightly improved to:
(perm | 0x2) != 14
In theory the compiler could then compile the remaining branches down into conditional moves, thus eliminating branch mispredict costs altogether, however it doesn't seem to be able to generate floating-point conditional move instructions at the moment (integer conditional move works fine).
Just tested it, it does apply to 1.7.2, and reduces world gen time by 7.5%.
Another small improvement: replacing
with
brings the total time reductions up to 9.3%. I also tried completely debranching the function – unfortunately without the ability to generate setnz or movcc instructions, it was worse than nothing.
My operating system has not packaged newer versions yet. Will respond when they are available (or if I can figure out a way to do a local install of the package from oracle's website).
Can confirm that it works as expected with the version of java from the Oracle website.
